Stable structure and simple operation:
12-position tool turret, allowing for flexible combinations of powered tool holders and standard turning tool holders:
Capable of machining complex components:
Integrated spindle unit design, requiring no maintenance.
Parameter | Unit | VS - 1250C |
Stroke | X-axis | mm | 700 |
Z-axis | mm | 850 |
Machining Capacity | Maximum swing diameter | mm | 1250 |
Maximum turning diameter | mm | 1100 |
Maximum turning height | mm | 800 |
Spindle speed | rpm | 30-600 |
Front bearing diameter | mm | φ200 |
Spindle Parameters | Spindle axial runout | mm | 0.003 |
Spindle radial runout | mm | 0.003 |
Spindle output rated torque | N.M | 950/2800(gearbox) |
Main Motor | Power | Kw | 30/22 |
Chuck/Turret | Chuck type | | Four-jaw manual chuck |
Chuck diameter | mm | φ800 |
Turret position | | Twelve workstations |
Tool holder | | □32/φ50 |
Power tool holder | | BMT65 |
X-axis guide rail | mm | 55 |
Z-axis guide rail | mm | 55 |
Lead Screw/Guide Rail | Z-axis lead screw | mm | φ50 |
X-axis lead screw | mm | 0.75 |
Cooling/Hydraulics | Cooling motor power | Kw | φ50 |
Hydraulic motor power | Kw | 1.5 |
Factory Precision | Positioning accuracy | mm | ±0.008 |
Repeatability | mm | ±0.005 |
Minimum movement unit | mm | 0.001 |
Weight | Overall dimensions | mm | 2650×2600×3400 |
Machine weight | mm | 12000 |
