MK-600 Mk Round Table Horizontal Axis Surface Grinding Machine

MK-600 Round Table Horizontal Axis Surface Grinding Machine

The MK Series Rotary Table Horizontal-Spindle Surface Grinder features a layout characterized by a fixed, rotating worktable; a dual-column crossbeam; a saddle that executes longitudinal reciprocating motion along the crossbeam; and a grinding head that performs vertical feed movements along the saddle. The overall structure is robust and compact, offering high precision, reliable performance, and excellent manufacturability, while remaining convenient to operate. By utilizing peripheral grinding with the grinding wheel, the machine enables the upper and lower surfaces of the workpiece to achieve demanding standards for parallelism, dimensional accuracy, and surface finish.

Model:
MK-600
Brand:
MASTON

Availability:

Quantity:



Inquire Add to Basket

Round Table Horizontal Axis Surface Grinding Machine

Product Description

Parameter	Unit	MK-600
(x-axis)	mm	450
(z-axis)	mm	300
(Maxswingdia.)	mm	φ600
(Maxtruningdia.)	mm	300
(Spindle speed)	rpm	1000-2500
(Spindle motor power)	KW	7.5
(Axis diameter of spindle)	mm	140
(Repeat positioig)	mm	±0.003
(positioig)	mm	±0.008
(platness)	mm	±0.005
(Least input increment)	mm	0.001
Rotation speed of the rotary electromagnetic suction table		50-200
Size of the grinding head grinding wheel		D350×40×127
X/Z-axis drive motor		22Nn/3KW
Rated load capacity of the table	KG	300
Motor power of the table	KW	0.37
Total weight of the machine tool	KG	7000
Floor area (length × width × height)	mm	2200×3000×2900
