It boasts a stable structure and simple operation.
Vertical or Horizontal Tool Turrets: Freely selectable options.
Integrated Spindle Unit: Maintenance-free design.
Parameter | Unit | VTC-1600 |
Stroke | X-axis | mm | 1000 |
Z-axis | mm | 1200 |
Machining Capacity | Maximum turning diameter | mm | 1700 |
Maximum machining diameter | mm | 1600 |
Maximum machining height | mm | 1200 |
Spindle Parameters | Spindle speed | rpm | 30-500 |
Front bearing diameter | mm | φ260 |
Spindle axial runout | mm | 0.003 |
Spindle radial runout | mm | 0.003 |
Rated torque of spindle output | N.M | 950/3600 (gearbox) |
Main Motor | Power | Kw | 37 |
Size | Overall dimensions | mm | 3000×2800×3900 |
Chuck/Turret | Chuck type | | Four-jaw manual chuck |
Chuck diameter | mm | φ1000 |
Tool turret position | | Four-position/Twelve-position |
Ball Screw/Guide Rail | X-axis guide | mm | 55 |
Z-axis guide | mm | 55 |
X-axis screw | mm | φ50 |
Z-axis screw | mm | φ50 |
Cooling/Hydraulic | Cooling motor power | Kw | 0.75 |
Hydraulic motor power | Kw | 1.5 |
Factory Precision | Positioning accuracy | mm | ±0.008 |
Repeatability | mm | ±0.005 |
Minimum movement unit | mm | 0.001 |
Weight | Machine tool weight | kg | 15000 |
