It has functions such as automatic feed of the grinding wheel shaft, rough and fine grinding, automatic switching of workpiece speed, automatic grinding wheel adjustment and automatic compensation after adjustment, and automatic axial positioning of the workpiece.
Parameter | Unit | VMK1000 |
Itinerary | X direction | mm | 700 |
Z direction | mm | 850 |
Processing capacity | Maximum turning diameter | mm | 1100 |
Maximum turning diameter (for turning) | mm | 1000 |
Maximum turning height | mm | 850 |
Spindle parameters | Speed | rpm | 50-600 |
Front bearing diameter | mm | φ200 |
Axial runout of the main shaft | mm | 0.003 |
Radial runout of the main shaft | mm | 0.003 |
Rated output torque of the main shaft | N.M | 700 |
Main motor | Power | Kw | 22 |
Chuck / Tool tower | Clamping plate form | | Three-jaw hydraulic self-centering chuck |
Clamping plate diameter | mm | φ630 |
Power | Kw | 37 |
Speed | rpm | 10000 |
Spindle specification | | HSK100 |
Screw/Slide Rail | X guide rail | mm | 55 |
Z guide rail | mm | 55 |
Cooling / Hydraulic | X lead screw | mm | φ50 |
Z lead screw | mm | φ50 |
Cooling motor power | Kw | 0.75 |
Factory accuracy | Hydraulic motor power | Kw | 1.5 |
Positioning accuracy | mm | ±0.008 |
Repeatability of positioning accuracy | mm | ±0.005 |
The smallest moving unit | mm | 0.001 |
